Redland Mini-Stonewold Interlocking Concrete Roof Tile
The Redland Mini-Stonewold Interlocking Concrete Roof Tile is a versatile, modern alternative to natural slate, offering clean lines, robust performance and long-term reliability. Designed for use on pitched roofs and suitable even for external wall cladding, this concrete tile provides a sleek, uniform appearance that works beautifully on both contemporary and traditional properties.
Manufactured by BMI Group UK Limited, the Mini-Stonewold tile meets the harmonised standard BS EN 490:2011, ensuring consistent quality and dependable weatherproofing. Its interlocking design enhances installation efficiency while delivering excellent wind resistance and water shedding performance. With a minimum pitch capability of 17.5°, it is a practical solution for a wide range of roof designs and building projects.
Colour Options
The Mini-Stonewold tile is available in three attractive tones, offering style choice without compromising durability:
Slate Grey – A refined, modern shade reminiscent of natural slate.
Tudor Brown – A warm, traditional colour that complements rustic and heritage builds.
Farmhouse Red – A richer, more distinctive tone for classic and characterful roofscapes.
Performance & Durability
With a coated surface finish, this concrete tile provides enhanced colour stability and protection against weathering. Its precise interlock and strong concrete composition ensure long-lasting performance, while excellent dimensional accuracy contributes to a clean, consistent roof finish.
Each tile measures 418mm x 334mm, with a hanging length of 398mm, ensuring flexible installation options. The system accommodates headlaps between 75mm and 125mm, allowing installers to adapt to pitch requirements from 17.5° up to vertical (90°). When laid at maximum gauge, coverage is highly efficient at 9.9 tiles per m², and the roof build-up remains durable and structurally robust.
Technical Specifications
Intended Use: Pitched roof covering or external cladding
Harmonised Standard: BS EN 490:2011
Surface Finish: Coated
Height / Thickness: 31mm
Length: 418mm
Width: 334mm
Hanging Length: 398mm
Minimum Pitch:
17.5° at 100mm headlap
22.5° at 75mm headlap
Maximum Pitch: 90°
Minimum / Maximum Headlap: 75mm / 125mm
Maximum Gauge: 343mm (22.5° and over)
Minimum Gauge: 293mm
Battens Required: 2.92 m/m² at maximum gauge
Recommended Battens:
38 x 25mm (rafters ? 450mm centres)
50 x 25mm (rafters ? 600mm centres)
Tiles per m²: 9.9
Fixings: 50 x 3.35mm aluminium alloy tile nails
Gross Weight per Tile: 5.176 kg
Weight per m²: 50 kg
Pallet Details: 36 tiles per pack; 216 tiles per pallet; approx. 1101.6 kg per pallet
Tile Mixing: Mix from 3 pallets to ensure colour consistency
Uniclass Reference: Pr_25_93_72_17
FAQs
Are Mini-Stonewold tiles suitable for low-pitch roofs?
Yes. They can be installed on roofs as low as 17.5° when using a 100mm headlap, making them ideal for a wide range of roof designs.
Do these tiles need special fixings?
They require 50 x 3.35mm aluminium alloy nails, and appropriate clips should be used where necessary to meet local wind-loading requirements.
How many tiles are needed per square metre?
At the maximum gauge, you will need 9.9 tiles per m², ensuring efficient coverage and simplified material planning.
