Stelrad Elite K2 Double Panel Vertical Radiator
The Stelrad Elite K2 Double Panel Vertical Radiator is designed to deliver dependable heating performance while maintaining a slim and stylish appearance. The Elite range has benefited from significant investment in quality and performance, resulting in improved heat outputs and efficient heating for commercial central water heating systems.
With its vertical design and compact panel construction, the Stelrad Elite is a practical option where wall space is limited. Its sleek appearance and classic Traffic White finish allow it to complement a wide range of commercial interiors, while the choice of three widths provides added flexibility when selecting the right size for your space.
Reliable Heating Performance
This Type 22 (K2) radiator features a double panel and double convector configuration, helping it provide effective heat distribution without taking up excessive wall space. The convectors are precision welded directly onto the waterways to support efficient heat transfer and reliable performance.
The radiator is manufactured from steel and finished with a smooth, powder-coated Traffic White finish in RAL 9016. High-definition pressings create smooth, sleek corners and edges, giving the radiator a clean and understated appearance that works well in both modern and traditional settings.
Quality Construction
Built to recognised industry standards, the Stelrad Elite conforms to BS EN 442 and is manufactured using an ISO 9001 quality system. It is designed to operate at a maximum working pressure of 10 bar (145 psi), making it suitable for commercial central water heating applications.
The radiator incorporates high-quality EPDM (Ethylene Propylene Diene Monomer) O-rings and comes equipped with a TBOE connection for added installation flexibility. A 10-year warranty provides additional reassurance and reflects the manufacturer's confidence in the radiator's quality and durability.
Available Sizes
The Stelrad Elite K2 Double Panel Vertical Radiator is available in three different widths, all with a height of 700mm. This range of sizes makes it easier to select a radiator that suits your available wall space and heating requirements.
- 700 x 400mm
- 700 x 500mm
- 700 x 600mm
The 700 x 400mm variant has a heat output of 414 Watts, equivalent to approximately 2,743 BTU/h. The wider 700 x 500mm and 700 x 600mm variants offer greater radiator surface area and are suitable where a higher heat output is required.
Key Features
- Type 22 (K2) double panel and double convector radiator
- Vertical, wall-mounted design
- Available in 700 x 400mm, 700 x 500mm and 700 x 600mm sizes
- Suitable for commercial central water heating systems
- Manufactured from durable steel
- Maximum operating pressure of 10 bar (145 psi)
- Conforms to BS EN 442
- Manufactured using an ISO 9001 quality system
- Precision-welded convectors for efficient heat transfer
- High-quality EPDM O-rings
- TBOE connection
- Smooth, high-definition pressed corners and edges
- Drip-free and waterproof powder-coated finish
- Classic Traffic White colour, RAL 9016
- Wall-mounted fixing system
- 1/2 inch BSP pipe inlet size
- 10-year warranty
Frequently Asked Questions
What sizes are available for the Stelrad Elite K2 Double Panel Vertical Radiator?
The radiator is available in three sizes: 700 x 400mm, 700 x 500mm and 700 x 600mm. Each variant is 700mm high, with the different widths providing flexibility for various wall spaces and heating requirements.
What type of heating system is the Stelrad Elite K2 suitable for?
The Stelrad Elite K2 is designed for use with commercial central water heating systems. It has a maximum operating pressure of 10 bar (145 psi) and conforms to BS EN 442.
What finish and colour does the radiator have?
The radiator features a smooth, powder-coated Traffic White finish in RAL 9016. Its classic white colour and sleek pressed edges make it easy to incorporate into a range of commercial interior styles.
